H13 H14 99.99% High Efficiency Silicone Gel HEPA Air Filter for Cleanrooms
Introduction
The H13 H14 99.99% HEPA filters, made of aluminum alloy frame that provide strong body;
Mini pleated glass fiber filter media, 100% waterproof, high performance, high efficiency that
can remove particle size as large as 0.3um 99.97 - 99.99% efficiency;
mini pleated design can maximize the filter area in limited space, enlarge air flow rate and dust holding capacity, reducing air pressure drop;
Sealed with polyurethane all around the aluminum slot, connect the aluminum frame with the filter pack
without any seam;
Gasket: silicone gel seal, that provide better performance more than normal neoprene gasket;
Application: for pharmaceutical & hospital cleanrooms;
micron electric factories` cleanrooms and so on;
Quality control: test every HEPA filters make sure it`s without air leakage;
Specifications:
Frame: Anodize aluminum
filter media: HV glass fiber
size; customized or standard size;
seal: silicone gel seal or neoprene seal;
sealant: polyurethane;
faceguard: painted metal mesh double side;
final pressure drop: 600 Pa;
Standard size and Technical data:
| model | Outside dimensions(mm) | Rated air flow(m³/h) | Initial resistance(Pa) | Final pressure drop(Pa) | Dust holding capacity(g) | Filtration area(m³) | Filter class |
| XN-CXZ-001 | 305*305*90mm | 250 | 160 | 400-600 | 200 | 3.1 | H12-H14 |
| XN-CXZ-002 | 484*484*90mm | 800 | 160 | 400-600 | 500 | 7.8 | H12-H14 |
| XN-CXZ-003 | 305*610*90mm | 406 | 160 | 400-600 | 320 | 6.2 | H12-H14 |
| XN-CXZ-004 | 610*610*90mm | 1000 | 160 | 400-600 | 750 | 12.2 | H12-H14 |
| XN-CXZ-005 | 915*610*90mm | 1500 | 160 | 400-600 | 1050 | 18.2 | H12-H14 |
| XN-CXZ-006 | 1220*610*90mm | 2000 | 160 | 400-600 | 1100 | 23.6 | H12-H14 |
hot-sale products
Packaging & Shipping
1. Each Product in Cartons to make sure the safety.
2. Package According to Customers` requirement is available;
3. Samples be shipped by DHL/FedEx/UPS and so on.
4. Mass production be shipping by Air or Sea.
Our Services
1. We could design and product accroding to our customers` requirement, with OEM/ODM.
2. Useing good raw material and advanced craft to ensure the product quality.
3. We have professional team to help you choose.
4.15 years experiences.
Company Information
Shenzhen XiangNan High-Tech Purification Equipment Co., LTD. Is engaged in the south central air conditioning clean engineering design, Construction and air purification equipment research and manufacturing company, one of the professional companies set "R&D, Design, Production, Sales, and Service". to provide customers with high quality technical service and clean stable quality and cheap air purification equipment, stable product quality considerate and professional after-sales service to win a nationwide electronic, mechanical, food, pharmaceutical, coating, hospitals, enterprises` trust.
Certifications
All of our products are compliant with CE, ROHS, ISO Certificate.
FAQ
Q: Are you trading company or manufacturer ?
A: We are a factory founded in 2002,and have 15 years experience in producing air filters professionally.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 50% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
Product Tags:
|
|
Silicone Gel hepa hvac filter hepa air filtration system 2 - 3 years Service life Images
|
